Part No.: 2809

Spring Loaded Binding Post


  • Quick and secure wire connection is assured with these spring loaded binding posts.
  • Heads and bodies are brass with plated finish as indicated.  Insualted caps on heads are available in read (-102) or black (-103) or for the Dual posts, a combination (RR, RB, BB).  Pelase add color as suffix to part number.
  • To connect to circuit, wrap wire around solder turret or attach to solder lug between nuts (lug not supplied).


Product Specifications
Mounting Hole: #6
Post Thread: 6-32
Stud Length: 6-32 THD
Plating: Nickel
